Solar LED Security Flood Light

Solar LED Security Flood Light
Solar LED Security Flood Light
Send Inquiry
Product Code : UHPSFL09
Brand Name : ULTRAHEAT
Price And Quantity
  • Minimum Order Quantity
  • 24
  • Unit of Measure
  • Piece/Pieces
  • Price
  • 1668 INR
Product Specifications
  • Product Type
  • Other
  • Power
  • 9w Watt (w)
  • Warranty
  • 5 years
Product Description
MODEL UHPSFL09
OPTICAL PARAMETERS OPTICAL PARAMETERS
LED Chip Type OSRAM DURIS E5
Number of LED Chip 18
Color Temperature 6000K-6500K
Light Power 9 WATT(+/- 10%)
Maxmimum Luminous Flux 1260 lumens
Beam Angle 120
Lumenious Density Lm/W 140
Dusk to Dawn Parameters NTTV (Night Time Threshold Voltage):3.0 vdc
LED Driver Efficiency Greater than 90 percent
Ideal Current Consumption Less than 5.0ma
Battery Low, Load Disconnect Voltage Lead Acid Batteries: 11.0vdc                                  Li-Ion Batteries: 14.0 vdc                                 LiFePO4 Batteries: 12.0 vdc
Battery Full, Load Re-connect Voltage Lead Acid Batteries:  12.5vdc                                 Li-Ion Batteries: 15.0 vdc                                 LiFePO4 Batteries: 13.0vdc
Battery Boost Voltage Set-point Lead Acid Batteries: 14.5vdc                                  Li-Ion Batteries: 16.4 vdc                                 LiFePO4 Batteries:  14.3vdc
Battery Float Voltage Set-point Lead Acid Batteries: 14.1vdc                                  Li-Ion Batteries: 16.4 vdc                                 LiFePO4 Batteries:  14.3vdc
  Short Circuit Protection, Battery Over-charge Protection, Battery Deep Discharge Protection, PV Reverse Voltage Polarity Protection
Electronic Protections Battery Reverse Voltage Polarity Protection, Software Watch-dog for LED  Over-current Protection
MECHANICAL PARAMETERS MECHANICAL PARAMETERS
Heat Sink Surface Temperature 65 'C
Storing Temperature 35 'C
Lifespan 60000 hours
Fixture Material Alluminium
Lamp base Metal core pcb
IP Level IP65
Product size 138mm x 179mm x 97mm
Product weight 1.1 kg
Warranty 5 year
Trade Information
  • Payment Terms
  • Cash in Advance (CID)
  • Delivery Time
  • 4-5 days within Delhi NCR
  • Packaging Details
  • cardboard packaging
  • Main Domestic Market
  • All India
